Solar Tracking for Roofs

OPTIM-TOP

OPTIM-TOP is a full patented solar tracking system with one polar axis, specially made for roofs, with the highest reliability and robustness.
With this system you can, easily and reliably, taking maximum advantage of any of the PV modules existing on the market.

Compact tracking system: minimum logistics and shipping costs

The one and only delivery package, without independent parts and elements, is ideal for shipping via standard sea container.
A foldable structure becomes (through an articulated parallelogram mechanism) a self-supporting structure which operates intuitive. This results in the fact that the structural strength of this assembled framework is fully independent from the roof where it will be set up.
OPTIM-TOP® is conceptually modular and scalable in order to joins up to 15 positions with a single power unit. This number is considered optimal because of the size of most industrial roofs.

Easy assembly Tracker: simplifies the set up and reduces costs

The main problem of the roof tracking systems -also for most of the fixed frameworks- is the troublesome handling and set up.

Modular Tracker: Suitable for any brand and type of PV module

Innovator "sliding clamps" system adapts to any photovoltaic module, whenever the frame is rigid enough to hold up the potential wind and snow loads.
The system is ideal for modules which have a thickness frame of between 35 and 50mm -those values include 95% of the modules on the market-.
Title:
Rooftop sun trackers
Autor:
optimtop
URL:
http://www.sun-tracker-optimtop.com
Create
2011-09-27
Forma parte de:
optimtop
OPTIM-TOP® is a full patented solar tracking system with one polar axis, specially made for roofs, with the highest reliability and robustness.
With this system you can, easily and reliably, taking maximum advantage of any of the PV modules existing on the market.



Maximum solar gain and respect for the environment

Thanks to our sun follower, you can reach a double target: act on behalf of the environment and take advantage of a 25% productivity increase compared to a fixed framework.
This productivity gain, joined with a minimum installation and maintenance cost, results in an improvement of 2 or 3 points on your investment, and a breaking even time reduction of between 2 and 3 years.
Productivity increase with tracking system    Productivity increase with tracking system
Production WITHOUT tracker OPTIMTOP Production WITH tracker OPTIMTOP

Quick and easy mounting tracker, maintenance free

The modularity of our tracker system, previously assembled, tested and certified, allows for easy mounting with the minimum time.
The compact delivery volume, consisting of only one package, assures you easy shipping, handling and storage.
We recommend a yearly review and oiling of some parts of the set in order to have it be in perfect working conditions.

Rooftop tracker mounting

Solar tracker reliability and robustness guaranteed

The design of the rooftop sun follower OPTIM-TOP® is based on a self-supporting structure able to hold wind loads of up to 150km/h.
The highest testing requirements done by APPLUS in order to obtain the certification of this product, allows us to offer you guarantees for more than 20 years on structure and 5 years on drive unit.

Wind loads over rooftop solar tracker Applus Certification

Solar tracker exclusive for roofs: Partner Program

Would you like to collaborate with us? We are looking for Partners for among the best engineering companies and / or installers, able to give their costumers a highly differentiated and quality service thanks to excellent OPTIM-TOP® performance.
We offer the best technical and commercial support for exclusive local markets.
Contact us here for more information.


Photovoltaic module Exclusive for roofs

Lightweight sun follower.
Certified.
Quick mounting, maintenance free.
